AVL-600W Series

Rechargeable Trailer Tracker

The AVL-600W Series are ruggedized waterproof GPS trackers specially designed for use in trailer, tanker, reefer and flatbed truck tracking. They include up to a 90-day standby time using an internal rechargeable 5200 mAh battery pack, and are able to dual external power sources for redundancy.

The built-in GPS receiver has best in class sensitivity and fast time to first fix.  Multiple I/O interfaces for monitoring temperature and multiple serial ports.  Vehicle trackers within the series support Quad Band 2G GSM/GPRS and multiple 3G variants with Global or Regional Applicability.

System Integration is straightforward as complete documentation is provided for the full-featured @Track protocol.  The @Track protocol supports a wide range of reports including position report, geo-fence alarm, low power alarm and more.

Dimensions:
  • 135 x 62 x 38 mm
Highlights:
  • Ruggedized, designed for use in harsh heavy trucking environments, sealed against common fuel oils and other hazardous chemicals
  • Multiple I/O interfaces for monitoring and controlling including composite inputs, ignition detection and serial port options
  • 1-wire interface for temperature sensors monitoring
  • Low power consumption, 90-day long standby time with internal batteries
  • Waterproof IP67 compliant
Features:
  • Dual band UMTS/HSPA, Dual band GSM/GPRS (North America)
  • Quad band UMTS/HSPA, Quad band GSM/GPRS (Worldwide)
  • Designed for trailer and harsh heavy tracking environment
  • 90 day long standby time with rechargeable internal battery
  • North America version is FCC, PTCRB, and AT&T certified
AVL-600W Series Data Sheet » Data Sheet
